When you have an irregular tank, use this calculator to calculate where to place your sensors vertically. If you have 3 sensors, you can, for example, select the 25%, 50% and 75% levels, which are shown at the bottom of the table. You can also print your calculation.
However, always remember that there is a minimum distance of 35 mm, to an edge of the tank and follow the instructions provided. They are also available at https://www.gobius.se/en/support-2/instructions/
Distance between sensors should not be less than 35 mm. You can always place the sensors diagonally on the tank and also on different sides. The most important thing is that the height is the desired one. We recommend for three sensors a minimum height of the tank, 200 mm.
If you have any questions, send them to us at https://www.gobius.se/en/contact/.
Good luck!
| Volume Level (%) | Height bottom (mm) | Height top (mm) |
|---|---|---|
| 100% | ||
| 90% | ||
| 80% | ||
| 70% | ||
| 60% | ||
| 50% | ||
| 40% | ||
| 30% | ||
| 20% | ||
| 10% | ||
| 0% |
| Volume Level (%) | Height bottom (mm) | Height top (mm) |
|---|---|---|
| 75% | ||
| 50% | ||
| 25% |
